5XFS Series Air Screen Cleaner
Capacity:10t/h
Power:10.5KW
Production Time:7 working days
For removing dust,light,bigger and smaller impurities
Power:10.5KW
Production Time:7 working days
For removing dust,light,bigger and smaller impurities
share:
Product Details
5XFS Series Air Screen Cleaner
Machine Grain Flow Chart
Machine Application
The 5XFS Series Air Screen Cleaner is the basic pre cleaning machine,based on the different capacity have three models;
The main function of the air screen cleaner is for removing the dust,light impurities by air screen part,removing the bigger and smaller impurites by sieves in grader part;
The machine can use for different grain,seeds and beans,but usually will connect with other machines,like destoner,gravity separator etc.
Machine Specification
| Machine Name | 5XFS-5C Air Screen Cleaner | 5XFS-7.5C Air Screen Cleaner | 5XFS-10C Air Screen Cleaner |
| Power | 5.4KW | 8.5KW | 10.5KW |
| Capacity | 5t/h | 7.5t/h | 10t/h |
| Sieves Size | 1000mm*2400mm | 1250mm*2400mm | 1500mm*2400mm |
| Weight | 1600kg | 1800kg | 2000kg |
| Overall Size | 5100*1900*3400mm | 5100*2100*3400mm | 5100*2300*3400mm |
| Voltage | 380V,50HZ,Three Phase | 380V,50HZ,Three Phase | 380V,50HZ,Three Phase |
Machine Video
