What is the 5XZ Gravity Separator used for?

The 5XZ Gravity Separator is used to separate seeds and grains based on their specific gravity. It efficiently removes light, immature, insect-damaged, or moldy seeds from heavier, healthy ones—improving overall seed quality and germination rates.

How does the gravity separation process work?

Material is fed onto a vibrating deck with controlled airflow. Heavier particles sink and move in one direction, while lighter ones float and move in another, allowing for precise density-based separation.

What types of materials can be processed with the 5XZ Gravity Separator?

It can process a wide range of crops, including wheat, maize, soybeans, coffee, sunflower seeds, sesame, beans, and other granular materials that require purity and uniform density.

What is the processing capacity of the 5XZ Gravity Separator?

Capacity varies by model, typically ranging from 2 to 10 tons per hour, depending on material type, moisture content, and impurity level.

Is the machine easy to operate and adjust?

Yes. The machine offers adjustable deck inclination, vibration speed, and airflow control, allowing operators to fine-tune performance for different crops. With basic training, it is easy to operate and maintain.

Gravity Separator for Sale - Efficient Gravity Table Seed & Grain Cleaner

5XZ Gravity Separator

Blowing Type
Capacity in 5-8t/h
Power in 13.2KW
Production Time in 7 working days
With Slope Elevator

Detalles del producto

Contact Now

Detalles del producto

5XZ Series Gravity Separator

Machine Grain Flow Chart

Machine Application

The 5XZ-8 Series Gravity Separator based on different capacity,we have three models,5XZ-8 Gravity Separator,5XZ-8C Gravity Separator,5XZ-15 Gravity Separator;

The Gravity Separator is for separating the good grain and seeds from the bad ones,the bad ones will be like moldy,blighted,insected empty inside etc.;

Gravity Separator usually use for seeds and beans fine cleaning.

Machine Specification

Machine Name	5XZ-8 Gravity Separator	5XZ-8C Gravity Separator	5XZ-15 Gravity Separator
Gravity Table Size	3150mm*1380mm	3150mm*1380mm	4150*1950mm
Power	13.2KW	14.3KW	25KW
Overall Size	3880mm1730mm1700mm	3880mm2020mm1700mm	5000mm2500mm2000mm
Weight	1700kg	1900kg	3000kg
Capacity	5t/h based on wheat	7-8t/h based on wheat	15t/h based on wheat
Voltage	380V,50HZ,Three Phase	380V,50HZ,Three Phase	380V,50HZ,Three Phase

Machine Video

Get in Touch

Si está interesado en nuestros productos, puede optar por dejar su información aquí y nos pondremos en contacto con usted en breve.

5XZ Gravity Separator FAQs

What is the 5XZ Gravity Separator used for?

The 5XZ Gravity Separator is used to separate seeds and grains based on their specific gravity. It efficiently removes light, immature, insect-damaged, or moldy seeds from heavier, healthy ones—improving overall seed quality and germination rates.
How does the gravity separation process work?

Material is fed onto a vibrating deck with controlled airflow. Heavier particles sink and move in one direction, while lighter ones float and move in another, allowing for precise density-based separation.
What types of materials can be processed with the 5XZ Gravity Separator?

It can process a wide range of crops, including wheat, maize, soybeans, coffee, sunflower seeds, sesame, beans, and other granular materials that require purity and uniform density.
What is the processing capacity of the 5XZ Gravity Separator?

Capacity varies by model, typically ranging from 2 to 10 tons per hour, depending on material type, moisture content, and impurity level.
Is the machine easy to operate and adjust?

Yes. The machine offers adjustable deck inclination, vibration speed, and airflow control, allowing operators to fine-tune performance for different crops. With basic training, it is easy to operate and maintain.
